I-Line Female X Male End 45 Degree Elbow (2PI)

$67.50
No reviews
EAGLE™ I-Line 2PI Female X Male End 45 Degree Elbow - Sanitary Fittings
EAGLE

I-Line Female X Male End 45 Degree Elbow (2PI)

From $67.50

Female X Male I-Line connection for 45° turns in sanitary process lines.


  • Female X Male End 45 Degree Elbow
  • Available in 304 & 316L Stainless Steel
  • 3A Certified for sanitary-grade line process equipment

Sanitary Fittings offers the 45° female x male elbow I-Line fitting connection with outside diameter (OD) sizes from 1" to 4". Available in both 304 & 316L stainless steel options. Items are typically in stock, please call for item availability. Product is 3A Certified.

I-Line fittings have a male and female connections ensure the rigidity of your sanitary process line systems. This interlocking design allows for a safe, compression connection reducing the chance of an intermediate gasket from interfering with process line product. I-Line fittings are the most durable with regards to vibration, temperature, and pressure.

Dimension


Size

A

B

C



inch

mm

inch

mm

inch

mm

1"

1.411

35.8

1.214

30.8

1.5

38.1

1.5"

1.879

47.7

1.526

38.8

2.25

57.1

2"

2.286

58.1

2.03

51.6

3

76.2

2.5"

2.723

69.2

2.412

61.3

3.75

95.2

3"

3.098

78.7

2.787

70.8

4.5

114.3

4"

3.848

97.7

3.537

89.8

6

152.4



Size OD

  • 1"
  • 1-1/2"
  • 2"
  • 2-1/2"
  • 3"
  • 4"

Grade

  • 304
  • 316L
