EAGLE ™ BPE DT-22 Clamp Ferrule Medium

1 / of 2

EAGLE ™ BPE DT-22 Clamp Ferrule Medium

$25.68

Unit price /

Unavailable

Size

1/2"
3/4"
1"
1 1/2"
2"
2 1/2"
3"
4"
6"

Finish

15RA/ PM/ SF4
20RA/ PL/ SF1

Product variants

EAGLE ™ BPE DT-22 Clamp Ferrule Medium - 1/2" / 15RA/ PM/ SF4 is backordered and will ship as soon as it is back in stock.

Qty

This item is a recurring or deferred purchase. By continuing, I agree to the cancellation policy and authorize you to charge my payment method at the prices, frequency and dates listed on this page until my order is fulfilled or I cancel, if permitted.

EAGLE ™ BPE DT-22 Clamp Ferrule Medium

From $18.20

Unit price /

Unavailable

Choose options

Product Name: BPE DT-22 Medium Clamp Ferrule

Product Description:

The BPE DT-22 Medium Clamp Ferrule is made from high-quality stainless steel and meets sanitary standards, making it suitable for use in food, pharmaceutical, and chemical industries. This product is precisely engineered to provide excellent sealing and corrosion resistance, ensuring the safe flow of liquids and gases through pipelines.

Specifications

Material: 304 or 316L stainless steel for durability and corrosion resistance.

Size: DT-22 Medium, compatible with various pipe diameters.

Design: Easy clamp design for quick installation and maintenance.

Standards: Compliant with BPE (Bioprocessing Equipment) and 3A sanitary standards.

Applications:

Ideal for industries with high sanitary requirements, including pharmaceuticals, biotechnology, food processing, and cosmetics manufacturing.

Dimension

Size	Dimensions
Size	Type	A in.	A mm	D in.	D mm
1 ⁄ 4	A	1.130	28.7	0.984	24.9
3 ⁄ 8	A	1.130	28.7	0.984	24.9
1 ⁄ 2	A	1.130	28.7	0.984	24.9
3 ⁄ 4	A	1.130	28.7	0.984	24.9
1	A	1.130	28.7	1.339	34.0
1	B	1.130	28.7	1.984	50.3
1 1 ⁄ 2	B	1.130	28.7	1.984	50.3
2	B	1.130	28.7	2.516	63.9
2 1 ⁄ 2	B	1.130	28.7	3.047	77.3
3	B	1.130	28.7	3.579	90.9
4	B	1.130	28.7	4.682	118.9
6	B	1.500	38.1	6.570	166.8
