EAGLE™ 3A Weld Ball Valves With Low Platform

$79.30
No reviews
EAGLE™ 3A Weld Ball Valves With Low Platform - Sanitary Fittings
EAGLE

EAGLE™ 3A Weld Ball Valves With Low Platform

From $79.30

Sanitary Manual Ball Valve for Easy Process Control

  • Sanitary Manual Weld Ball Valves
  • Steel 304 Body, Steel 316L for fluid contact
  • Working Pressure 10 Bar
  • EPDM Sealing: -20℃ ~ 135℃ ( 150℃ Max 20min)


316L/304 manual ball valve is a type of ball valve that has a full inclusive ball seat design that solves the problem of the liquid holdup of the valve cavity. It is suitable for bio pharmaceutical engineering. The stem seal is in patent design and spring in compensation type design which have the advantage of long life, low torque, long-term use under high temperature 150 ℃.

Dimension

Size

D1

L

W

H

1/2"

12.7

91

130

62

3/4"

19.05

102.5

130

68.5

1"

25.4

114.8

176

74.5

1 1/4"

31.8

125

170

74.5

1 1/2"

38.1

137.3

226

98

2"

50.8

156.4

226

100

2 1/2"

63.5

171

326

123.5

3"

76.2

196.7

325

150

4"

101.6

242

332

159

Technical Support





OD Size

  • 1/2"
  • 3/4"
  • 1"
  • 1 1/2"
  • 2"
  • 2 1/2"
  • 3"
  • 4"

Grade

  • 304
  • 316L
