What Sizes Does Stainless Steel Pipe Come In?

What Sizes Does Stainless Steel Pipe Come In?

Stainless steel pipes are the backbone of industries like oil and gas, food processing, and construction—but selecting the right size is critical for performance, safety, and cost efficiency. With endless variations in diameter, wall thickness, and length, navigating stainless steel pipe sizes can feel overwhelming. In this guide, we’ll simplify standard and custom sizing options and showcase why Eagle’s stainless steel pipes deliver unmatched precision, durability, and compliance for projects worldwide.

Standard Stainless Steel Pipe Sizes

Stainless steel pipes are categorized by outer diameter (OD), wall thickness (schedule), and length. Eagle stocks a comprehensive range to meet global standards:

1. Outer Diameter (OD) Ranges

Small Pipes: 1/8" (3.18 mm) to 2" (50.8 mm) – Ideal for instrumentation, medical devices, and beverage lines.

Medium Pipes: 2" (50.8 mm) to 12" (304.8 mm) – Used in HVAC, plumbing, and chemical processing.

Large Pipes: 12" (304.8 mm) to 48" (1,219 mm) – For oil/gas pipelines, water treatment, and structural applications.

2. Wall Thickness (Schedule)

Thin-Wall: Schedule 5S to 10S (0.065"–0.134") – Lightweight for low-pressure systems.

Standard: Schedule 40 (0.154"–0.438") – Balances strength and cost.

Thick-Wall: Schedule 80 to 160 (0.188"–0.718") – Handles extreme pressures and corrosive fluids.

3. Lengths

Standard: 20 ft (6 m) for easy transport and handling.

Custom: Eagle offers cut-to-length services (1 ft to 40 ft) to minimize waste.

Stainless Steel Pipe Sizes by Application

Industry Common Sizes Eagle’s Recommended Grades
Food & Pharma 1/2"–6" OD, Schedule 10S–40S 316L (sanitary, electropolished)
Oil & Gas 2"–24" OD, Schedule 40–160 Duplex 2205 (high chloride resistance)
Architecture 1/4"–12" OD, thin-wall 304 (aesthetic, corrosion-resistant)
Chemical Processing 3"–18" OD, Schedule 80–160 317L (acid and heat resistant)
Tri-Clamp x Butt Weld 45 Degree Elbow Pipe fitting

Eagle’s Stainless Steel Pipes: Beyond Standard Sizes

Eagle combines global standards with bespoke engineering to solve unique project challenges:

1. Custom Diameters & Thicknesses

Micro Pipes: As small as 0.5 mm OD for specialized medical or aerospace uses.

Jumbo Pipes: Up to 60" OD for industrial ducts and offshore platforms.

Heavy-Wall Customization: Schedule 320 (1" wall) for ultra-high-pressure systems.

2. Precision Tolerances

OD Tolerance: ±0.5% for seamless pipes (ASTM A312).

Wall Thickness: ±10% for welded pipes (ASTM A358).

3. Material Excellence

Grades Available: 304/304L, 316/316L, 321, 347, duplex, super duplex.

Certifications: ASTM, ASME, EN, PED, and NACE MR0175.

Case Study: Eagle’s Custom Pipes Rescue a Geothermal Project

1. Background

A geothermal plant in Iceland needed 1,200 meters of 14" OD, Schedule 120 pipes to handle 600°F (315°C) brine with high sulfur content.

2. Challenge

Off-the-shelf pipes corroded within months, causing leaks and unplanned shutdowns.

3. Conflict

Replacing pipes every 6–8 months cost $2M annually in downtime and repairs.

4. Turning Point

Eagle’s engineers proposed super duplex 2507 pipes with a 2.5 mm internal cladding.

5. Solution

Custom Sizing: 14" OD, 1.2" wall thickness with enhanced ID smoothness.

Corrosion Testing: Passed 5,000-hour salt spray and H₂S exposure tests.

6. Results

Zero Leaks: 3+ years of uninterrupted operation.

$1.8M Saved Annually: Reduced maintenance and downtime.

stainless pipe

How to Choose the Right Pipe Size

1.Calculate Pressure Needs: Use the formula t=P×D/2×S×E+P×Y to determine required wall thickness.

2.Prioritize Flow Rate: Larger diameters reduce pressure drop in high-volume systems.

3.Match Material to Fluid: Acidic or high-chloride fluids require 316L or duplex grades.

Why Eagle Outperforms Competitors

  • Global Stock: 80% of orders ship within 48 hours.
  • Free Engineering Support: Eagle’s team helps with sizing, material selection, and compliance.
  • Sustainability: 90% recycled content with ISO 14001-certified production.

FAQ: Stainless Steel Pipe Sizing

Q: What’s the difference between Schedule 40 and 80?

A: Schedule 80 has thicker walls (e.g., 2" OD: 0.218" vs. 0.154") for higher pressure tolerance.

Q: Can I get non-round stainless pipes?

A: Yes! Eagle supplies square, rectangular, and oval pipes for architectural or structural needs.

Q: Are Eagle’s pipes suitable for cryogenic use?

A: Absolutely. Eagle’s 304L and 316L pipes meet ASTM A312 standards for -425°F (-254°C) applications.

Stainless steel pipe sizes vary widely, but the right choice hinges on your project’s pressure, temperature, and corrosion risks. While generic suppliers offer limited options, Eagle delivers precision-engineered pipes in every size imaginable—from micro-scale medical tubing to jumbo industrial pipelines. Their commitment to quality, customization, and fast delivery makes them the go-to partner for industries demanding reliability.
