Sanitary Ball Valve Overview

A Sanitary Ball Valve is a precision-engineered quarter-turn valve designed for sterile processing applications. Its spherical disc (ball) with a bore through the center provides excellent flow control while maintaining a hygienic, crevice-free design that prevents bacterial growth and contamination.

Key advantages:

  • Hygienic Design: Smooth, polished surfaces with zero dead legs
  • CIP/SIP Compatible: Designed for Clean-in-Place and Sterilize-in-Place systems
  • Quick Operation: 90-degree turn for full open/close operation
  • Low Maintenance: Simple design with minimal wearing parts

Key Features & Benefits

Full Bore Design

Minimal pressure drop and complete drainage, eliminating product entrapment.

Multi-Material Options

316L stainless steel bodies with PTFE, EPDM, or Silicone seals for various media.

Zero Dead Leg Construction

Crevice-free design prevents bacterial growth and simplifies cleaning.

Certified Sanitary Standards

Compliant with 3-A, EHEDG, FPSA, FISA, and ASME BPE standards.

Quick Delivery

Standard models ship within 1 week. Custom configurations available with flexible lead times.

Custom Solutions

Tailored to your specific process requirements with various connections and actuation options.

Applications & Industries

Our sanitary ball valves are essential components in industries where product purity, sterility, and contamination prevention are critical:

Pharmaceutical & Biotech

  • API processing lines
  • Bioreactor systems
  • Purification skids
  • Sterile filling lines

Food & Beverage

  • Dairy and cheese processing
  • Brewery and winery transfer
  • Bottling and canning lines
  • Sauce and condiment systems

Cosmetics & Personal Care

  • Cream and lotion manufacturing
  • Fragrance and perfume lines
  • Shampoo and conditioner filling
  • Toothpaste production

Dairy & Beverage

  • Milk and yogurt processing
  • Juice and concentrate systems
  • Soft drink production
  • Brewery fermentation

Technical Specifications

Parameter Specification
Size Range 1/2" to 4" (DN15 to DN100)
Pressure Rating Up to 150 psi (10 bar)
Temperature Range -20°C to 150°C (-4°F to 302°F)
Connection Types Tri-clamp, ISO, SMS, Bevel Seat, Weld ends
Body Material 316L Stainless Steel (Ra ≤ 0.8 μm)
Seat Materials PTFE, EPDM, Silicone, FKM
Actuation Options Manual lever, Pneumatic, Electric

Note: Custom configurations available. Standard delivery within 1 week. All valves are 100% pressure tested and cleaned before shipment.

Why Choose Us?

Industry Expertise

Specialized in sanitary valves with extensive experience across regulated industries.

Quality Assurance

Every valve undergoes rigorous testing including pressure, material, and surface finish verification.

Custom Engineering

Tailored solutions for unique applications with various sizes, connections, and materials.

Fast Delivery

Standard products ship within 1 week. Reliable logistics to destinations worldwide.

Our Certifications & Standards

3-A Symbol EHEDG FPSA FISA ASME BPE

Frequently Asked Questions

What are sanitary valves?

Sanitary valves are specifically designed for applications requiring high levels of cleanliness and sterility, such as food, pharmaceutical, and biotechnology industries. They feature smooth, crevice-free surfaces, easy cleaning capabilities, and materials compliant with industry standards to prevent contamination and bacterial growth.

What are the four types of ball valves?

The four main types of ball valves are: 1) Full Port (full bore) with minimal flow restriction, 2) Reduced Port (reduced bore) with smaller ball opening, 3) V-Port with V-shaped ball for better flow control, and 4) Trunnion Mounted with additional mechanical support for high-pressure applications. Sanitary ball valves typically use full port designs for complete drainage.

How often should sanitary ball valves be maintained?

Maintenance frequency depends on operating conditions, but we recommend routine inspection every 6-12 months. Sanitary ball valves are designed for minimal maintenance, with seal replacement typically needed only after several years of normal use.

Are your valves suitable for CIP (Clean-in-Place) systems?

Yes, all our sanitary ball valves are designed for CIP and SIP (Sterilize-in-Place) applications. They feature smooth, polished surfaces and materials resistant to cleaning agents and high-temperature sterilization.

What is your delivery time?

Standard sanitary ball valves typically ship within 1 week. Custom configurations may require additional time based on specifications. We provide accurate delivery estimates with every quotation.

Do you offer custom configurations?

Yes, we specialize in custom sanitary solutions. We can tailor valve size, connection type, material specifications, and actuation methods to meet your specific process requirements.

Have more questions? Contact our support team →

About Egle

Eagle Ultrapure Fittings- ASME BPE

Eagle branded production includes Sanitary Fittings, Valves, Pipes, Adapters and Tank Fittings like Manways and Spray Balls. The high quality products are mainly used in Food, Beverage and Dairy applications.
